The 5 steps to your suitable EyeVision software solution
Step 1
Download the fully usable demo version of our software free of charge
Step 2
Try out our software and reproduce work processes. Take a look at our YouTube channel for product demonstrations!
Step 3
Are you convinced and just as enthusiastic about our product as we are? Then let us know!
Step 4
Simply send us your used commands and required functions with the automatically generated license file
Step 5
We configure the software package for you with the functions that you really need
5 EyeVision software packages – individually expandable
EyeVision Software
 |  |
 |  |
The EyeVision Machine Vision Software and EyeVision 3D Software offers solutions for different applications, such as e.g.:
- 1D and 2D measurement and evaluation (support of numerous line scan and matrix cameras)
- Thermography capture and evaluation with special commands (for active, passive and lock-in thermal imaging)
- Hyperspectral Imaging capture and evaluation
- Evaluation on color and gray scale images
- Measurement and inspection technology
- Surface inspection also with Machine Learning algorithms
- Error detection
- Pattern matching
- Code Reading (DMC, QR, Barcode) as well as OCR/OCV
- Object detection and counting
- Position control
- Color inspection
- contour inspection, etc.
EyeVision 3D Software
The key function of the EyeVision 3D software is the recording and use of 3D recordings (point clouds).
Based on the point cloud, EyeVision 3D has various commands to:
- Recognize and count objects
- To find bugs
- carry out various measurement technology operations
EyeScan 3D sensors for the EyeVision 3D software
With the 3D camera system EyeScan 3D, EVT opens up the third dimension to the user.
- 3D capture and evaluation on the point cloud for e.g. pin inspection, bin picking, etc.
- 3D profile measurement for e.g. weld seam, adhesive bead and sealant inspection, etc.
3D sensors can be used in all industries, such as:
- for quality inspection
- for controlling robots
- for µ-precise measurement technology
EyeScan 3D means for the user:
- a fully calibrated 3D sensor – based on laser triangulation or area measurement
- The entire evaluation software EyeVision 3D is already included in the system and is programmed using drag-and-drop.
Here you will find some examples such as EyeVision 3D
- to optimize production processes,
- to improve quality control and
- to reduce manufacturing costs
Application examples for the EyeVision 3D would be:
tire imprint | weld seam |
 |  |
tire productionFor the tire production a 100%-quality control is indispensable. A 3D inspection also detects the black print on a black tire. At the same time also other surface defects can be detected. Download | weld seam inspectionEyeVision 3D checks for weld width and length, countersink free finish, weld seam joint or collapses, unequalsidedness, holes and surface pores. Download |
Glue | Sealant |
 |  |
Inspection of adhesive applicationsNoncontact and nondestructive inspection immediately after the application of the adhesive bead. Suitable for all glues and surfaces. EyeVision 3D recognizes flaws such as e.g.: discontinuity, thickening and position errors of adhesive beads. Download | Sealing compound inspectionEyeVision 3D inspects if the sealing compound is applied correctly and checks the positioning of the sealing compound. EyeVision and the EyeScan 3D Sensor guide the robot. Download |
Electronic | Smart Phone |
 |  |
PCB InspectionEyeVision 3D inspects at the soldering process and checks the component parts for: alignment, position, presence… | Smart Phone InspectionEyeVision 3D inspects small-format substrates as e.g. for smart phones. Measures fixed component parts and wavelength-dependent transmissions of filter layers on glass substrates. Download |
groceries | consumer goods |
 |  |
groceries inspectionEyeVision 3D scans size and shape of e.g. fruits and sorts them accordingly afterwards. This process prevents rejection. Download | inspection of parts of watchesEyeVision 3D checks on shape-defects fuch as e.g.: cylindrical form, corrugation, circularity. Additionally geometrical dimensions e.g.: diameter, height, width, etc. Download |
cast metal | gap inspection |
 |  |
cast metal inspectionThe 3D sensor scanns cast metal parts and compairs the scanned image with the CAD-data. EyeVision 3D inspects the shape and measurements during the production process. Download | gap inspectionEyeVision 3D inspects different gap types e.g.: simple gap, projection-gap, gap with bottom, advanced gap, … Download |
bin-picking | scan of large surfaces |
 |  |
EyeVision 3D für bin-pickingEyeVision 3D captures component parts in every position and rotation. Reacts on position changes of the objects. EyeVision 3D allows a complete usage of the robot line. Download | EyeVision 3D to scan large areas and objectEyeVision 3D can scan large surfaces and can display it undistorted with the 3D Unrolling command, without the need of an axis or robot. Download |
EyeVision Thermo Software
 |  |
 |  |
The EyeVision image processing software offers solutions for thermography. such as:
- Thermography acquisition and evaluation with special commands (active, passive and lock-in thermography)
- Temperature measurement
- Weld detection
- Glue dot detection
- Temperature distribution in thermoforming processes
- Control of fiber composites
- Electrical component testing
- Testing of precision resistors
- Leak test, packaging control
- Control of the seal seam, sealing and plastic welding processes
- Troubleshooting in the area of high and low voltage
- Pipeline insulation refractory lining of furnaces
- Optimization of casting molds
- Level detection of containers
EyeVision hyperspectral software
- Analysis and visualization of substance compositions
- Recognizing and differentiating substances
E.g. rubber parts in tobacco, ripe fruits and unripe fruits
EyeVision Deep-learning software
 |  |
 |
- The algorthims can be integrated in any machine vision software.
- The tool can be deployed in a ROI using for example the size of the anomaly surface defect as qualification criterion.
- no teaching in advance
- no setting parameters,
- as the algorithm adapts itself automatically to any random surface
- evaluation of the inspected surface in less than 50 ms on Core i3
Further information about the software
EyeVision is synonymous for “zero-error-production”, a reduction of production time, for quality and production acceleration and therefore als for a higher customer satisfaction.
Thanks to fast installation and univeral usage, the software creates a fast, efficient and cost-effective solution for all applications.
The packages contain different command sets. But the extendibility of the EyeVision software are unlimited:
You can add any command any time to any package.
Additionally, there are special command sets such as:
- ChipControl (for the semiconductor industry)
- Commands for color inspection
- Code Reader commands
Those can also be added to each package. Individually, depending on application and demand.
Drag-and-drop programming
The software is flexible and easy to handle. EyeVision is programmed via the graphical user interface (GUI). The easy programming via drag-and-drop is a well-known feature of the image processing software.
The intuitive user interface allows the creation and configuration of new inspection processes very easy and fast. Thanks to the innovative technique the handling is even for less experienced user very easy.
Flexible hardware choice
EyeVision supports line scan, matrix, color, gray scale, thermal imaging and 3D sensors with following interfaces:
- USB 2.0, 3.0
- GigE
- GenICam compatible cameras
- FireWire
- Camera Link
- RS232
- CoaXPress
The image processing software runs on ARM, x86, x64 and MIPS.
Image processing software for the Smart Camera
Additionally, the EyeVision is also available on the smart camera series EyeCheck and the vision sensor series EyeSens.
MIPI Software EyeVision
MIPI CSI-2 is already an important interface for mobile devices like smart phones or tablets, but also in image processing and many Embedded Vision applications it plays an important role.
EyeVision supports MIPI sensors by Allied Vision Technology, Basler, Vision Components and Raspberry Pi. This is a list which will grow even longer.
For the implementation of an embedded vision solution with MIPI sensors, EyeVision supports also the following boards:
Asus® Asus® Tinkerboard (Processor: Rockchip® RK3288) | Auvidea Auvidea NVIDIA® Jetson™ J100 (Processor: NVIDIA® TX1) Auvidea NVIDIA® Jetson™ AGX Xavier™ Carrier |
DragonBoard™ DragonBoard™ 410C (Processor: Snapdragon™ 410E) DragonBoard™ 820C (Processor: Snapdragon™ 820E) | Geniatech 4 IoT – Geniatech (Processor: Snapdragon™ 410E) |
HiKey HiKey960 (Processor: Kirin™ 960) HiKey970 (Processor: Kirin™ 970) | HummingBoard™ HummingBoard™ (Processor: NXP i.MX6) HummingBoardPro™ (Processor: NXP i.MX6) |
MediaTec MediaTec X20 (Processor: Helio X20) | MSC MSC SM2-MB-EP1 (Smarc carrier board) |
